- Detect tilt, orientation, or angular movement with the SW-520D Tilt Angle Sensor Module. This compact and reliable module is perfect for motion detection, security alarms, robotics, and DIY electronics projects. Compatible with Arduino, ESP8266, Raspberry Pi, and other microcontrollers, it’s an essential component for STEM learning and hobbyist experiments.
- ✅ Features:
- Tilt Detection: Detects angular movement and orientation changes
- Digital Output: Provides HIGH or LOW signal when tilted
- Indicator LED: Onboard LED shows output status for easy debugging
- Compact & Lightweight: Fits easily into small projects and enclosures
- Plug & Play: Works seamlessly with Arduino, ESP32, ESP8266, and Raspberry Pi
- Adjustable Sensitivity: Slight tilt can trigger output for flexible applications
- ⚙️ Specifications:
- Model: SW-520D Tilt Angle Sensor Module
- Operating Voltage: 3.3V – 5V DC
- Output: Digital (High/Low)
- Sensor Type: Tilt / Switch
- Module Dimensions: Approx. 3.2cm × 1.4cm
- Pins: VCC, GND, DO
- 💡 Applications:
- Robotics & automated motion detection
- Security alarm and anti-theft systems
- DIY tilt-sensitive projects and STEM experiments
- Arduino, ESP8266, and Raspberry Pi learning projects
- 📦 Package Includes:
- 1 × SW-520D Tilt Angle Sensor Module
Description
Description
The SW-520D Tilt Sensor Module is a simple and effective way to detect tilt or orientation changes in your projects. This module uses a cylindrical tilt sensor and an LM393 comparator to output digital HIGH/LOW signals based on the angle of tilt. It’s widely used in balance detection, fall alarms, motion-triggered lighting, and robot positioning systems.
This plug-and-play sensor module is perfect for Arduino, Raspberry Pi, and other microcontroller platforms, especially in beginner and school-level electronics kits.
✅ Key Features:
📐 Detects tilting and orientation changes
🔁 Digital output (High/Low) for easy interfacing
🔄 Adjustable sensitivity via onboard potentiometer
💡 Power and output LED indicators
🧩 Compatible with Arduino, ESP, Raspberry Pi, etc.
📐 Specifications:
ParameterDetailsSensor TypeSW-520D cylindrical tilt switchOperating Voltage3.3V – 5V DCOutput TypeDigital (HIGH/LOW)Comparator ChipLM393Interface3-pin (VCC, GND, D0)Sensitivity ControlOnboard potentiometerIndicatorsPower LED (Green), Output LED (Red)Dimensions~32mm x 14mmMounting HolesYesResponse TimeInstant tilt detection
🚀 Applications:
Tilt-detection alarms
Fall-prevention systems
Smart motion-activated lighting
Orientation sensing in robotics
Home automation and smart toys
Educational & STEM projects
